Factory Outlet Plastic Pipe Injection Molding Machine 90 Ton Plastic Injection Molding Machine
- Overview
- Recommended Products
Specification
ZLMC90S |
||||||||
Injection part |
||||||||
INJECTION UNIT |
unit |
A |
B |
C |
||||
Screw diameter |
mm |
30 |
35 |
40 |
||||
Shot volume |
cm³ |
120 |
163 |
214 |
||||
Shot weight(PS) |
g(ps) |
112 |
152 |
199 |
||||
Injection pressure |
MPa |
250 |
183 |
140 |
||||
Theoretical Injection rate |
cm³/s |
65 |
88 |
115 |
||||
Plasticizing Capacity(ps) |
g/s |
9.5 |
11 |
13.5 |
||||
Screw I/D ratio |
I:D |
23:1 |
21:1 |
18:1 |
||||
Screw speed(stepless) |
rpm |
0-213 |
0-213 |
0-213 |
||||
Screw stroke |
mm |
170 |
170 |
170 |
||||
Clamping part |
||||||||
Clamping force |
KN |
900 |
||||||
Opening stroke |
mm |
320 |
||||||
Max.daylight |
mm |
680 |
||||||
Mold thickness(min-max) |
mm |
130-360 |
||||||
Space between tie bars |
mm |
360x360 |
||||||
Platen size |
mm |
540x540 |
||||||
Hydraulic ejection force |
kN |
28.5 |
||||||
Hydraulic ejection stroke |
mm |
100 |
||||||
Power/Electricity/Other |
||||||||
Hydraulic system pressure |
MPa |
16 |
||||||
Motor/Server |
KW |
11 |
||||||
Heating capacity |
KW |
6.5 |
||||||
Oil tank capacity |
L |
130 |
||||||
Machine weight |
Kg |
3000 |
||||||
